Droplet Fusion Instrument
Equipment Introduction
The Droplet Fusion Instrument is an instrument used for high-throughput fusion of two different sizes of droplets.
Specification
| Pressure output channels | 4 channels |
| Droplet monitoring | Real-time monitoring of droplet pairing and fusion status |
| Droplet sampling volume | ≥ 10 million |
| Droplet fusion chip | 50 μm chip |
| Droplet fusion rate | 1.5 KHz |
| Droplet fusion success rate | ≥95% |
| Monitoring module | microscope resolution 1 μm, CMOS: 2592* 208,42.75 fps |
